Home/Water play/Elements/Ball & Jet Target

Ball & Jet Target

Aim a nozzle, shoot a floating ball into a ring.

Ball & Jet Target — water play element, 2700 × 1500 × 2300 mm
Standard build2700 × 1500 × 2300 mm
GroupBalls & Sensory
Standard size2700 × 1500 × 2300 mm
WaterRecirculated from the basin; the element drains back by gravity
Power220–240 V, single phase — pump duty set by the zone loop
MaterialsSUS304 frame · HDPE touch surfaces · cast acrylic windows
SupplySingle unit or batch · OEM to your drawing
Lead timeStandard 4–8 weeks after deposit (confirmed per contract)
Warranty1 year, structure and control
DocumentsSpecification sheet · control diagram · spare-part list

A standard element: the geometry and the finish are fixed, which is what keeps the price and the lead time predictable. Size, colour and the way it mounts to the basin can be adapted without a new design cycle.

Ask about this element → Email us
01 / Overview

A hand-aimed nozzle on a swivel, a supply of light balls, and a ring target set on a mast. Water carries the ball across the gap and through the ring.

02 / How it works

The ball rides a jet of water rather than being thrown, so the visitor controls a stream and the stream does the work — aim is everything, force is nothing. Hitting the target is genuinely difficult, which is why the queue keeps coming back.

03 / What visitors do

Load, aim, fire, miss, adjust. Pairs compete; adults take it far too seriously.

04 / In a zone

Needs a clear 2.7 m of open water in front of the target and a catch net behind it, or the balls end up in the wrong part of the building.
