Insert-a-Plate Flow Wall

A long shallow table where visitors build the channel themselves.

Insert-a-Plate Flow Wall — water play element, 4600 × 2000 × 470 mm
Standard build4600 × 2000 × 470 mm
GroupConveying & Flow
Standard size4600 × 2000 × 470 mm
WaterRecirculated from the basin; the element drains back by gravity
Power220–240 V, single phase — pump duty set by the zone loop
MaterialsSUS304 frame · HDPE touch surfaces · cast acrylic windows
SupplySingle unit or batch · OEM to your drawing
Lead timeStandard 4–8 weeks after deposit (confirmed per contract)
Warranty1 year, structure and control
DocumentsSpecification sheet · control diagram · spare-part list

A standard element: the geometry and the finish are fixed, which is what keeps the price and the lead time predictable. Size, colour and the way it mounts to the basin can be adapted without a new design cycle.

Ask about this element → Email us
01 / Overview

A 4.6-metre water table with a grid of slots across its bed. Loose plates drop into the slots to dam, divert, narrow or split the flow.

02 / How it works

Narrow the channel and the water speeds up; dam it and the level rises until it finds another way. Because the plates are loose, the same table gives a different result every time it is rebuilt — the fastest way to teach that flow rate is a function of cross-section.

03 / What visitors do

Build a channel, then test it. Most groups end up racing two routes side by side to see which one empties first.

04 / In a zone

A standing-height table rather than a basin element, so it works on the dry side of a pool or on its own in a discovery gallery. Water is recirculated from a sump under the table.
